1 Ton Electric Chain Hoist, hook suspended 2-motion type
Winches and Lift HoistsSKU BVZ-0101 / BVZ-0102

1 Ton Electric Chain Hoist

Beta Crane 1 t electric chain hoist models BVZ-0101 / BVZ-0102: hook suspended (2-motion) or electric trolley (4-motion), ISO M4, 24 V control, 2-year warranty.

  • Capacity1000 kg
  • Duty ClassISO M4
  • Power Supply3 phase, 220 – 440 V, 50 / 60 Hz
  • Model CodesBVZ-0101, BVZ-0102
  • Made in Türkiye
  • CE and TSE standards
  • Technical service
  • Spare part support

Data sheet

Technical specifications

Standard values; capacity, span and lifting height are adapted to your project.

1 Ton Electric Chain Hoist · BVZ-0101 / BVZ-0102
Model Codes
BVZ-0101, BVZ-0102
Capacity
1000 kg
Types
2-motion (hook suspended) or 4-motion (electric trolley)
Chain Reeving
1/1 or 2/1
Lifting Speed (single / dual)
1/1: 6.8 / 2.3 m/min; 2/1: 3.6 / 1.2 m/min
Lifting Motor (single / dual)
1/1: 1.5 / 0.6 kW; 2/1: 1.1 / 0.37 kW
Chain Diameter
1/1: 7.1 mm; 2/1: 6.3 mm
Trolley Travel Motor
0.4 kW
Trolley Travel Speed
11 m/min
Suitable I-Beam
80 – 160 mm
Lifting Height
Hook suspended 3 m, trolley 6 m standard; chain to required length
Duty Class
ISO M4
Power Supply
3 phase, 220 – 440 V, 50 / 60 Hz
Control
Pendant control, 24 V
Motor
Copper-wound
Gears
Heat-treated
Warranty
2 years

Beta Crane · +90 224 323 00 17 · destek@betavinc.com

Description

Applications and features

1 Ton Electric Chain Hoist

The 1 tonne electric chain hoist is the most popular capacity for workshops, maintenance and assembly benches, loading parts and tooling onto CNC machines and changing moulds and fixtures. Its light body hangs easily from an existing beam or a jib crane.

This page brings together all Beta Crane 1 tonne electric chain hoist models (BVZ-0101, BVZ-0102). Each model is built in two types: a 2-motion type that hangs from a fixed point by its suspension hook, and a 4-motion type that runs on an I-beam with an electric trolley.

Model options

ModelMotionsChain reevingLifting speed (m/min)Lifting motor (kW)Chain (mm)Headroom H (mm)
BVZ-01012 (hook suspended)1/16.8 / 2.31.5 / 0.67.1600
BVZ-01022 (hook suspended)2/13.6 / 1.21.1 / 0.376.3670
BVZ-01014 (electric trolley)1/16.8 / 2.31.5 / 0.67.1650
BVZ-01024 (electric trolley)2/13.6 / 1.21.1 / 0.376.3640

2-motion or 4-motion?

A 2-motion (hook suspended) hoist only lifts and lowers; it hangs from the roof, a beam or a jib crane. It is enough for bench work where the load is always picked up at the same point, and for freight lifts.

A 4-motion (electric trolley) hoist also travels along an I-beam. At this capacity the trolley fits 80 – 160 mm beams and runs at 11 m/min with a 0.4 kW travel motor. This type is used on monorail lines and single girder overhead cranes.

Choosing the chain reeving

The single fall (1/1) BVZ-0101 model lifts fastest at 6.8 / 2.3 m/min. On the multi-fall BVZ-0102 (2/1) the speed drops to 3.6 / 1.2 m/min, but the chain and motor are under less load and the hook positions more precisely. Single fall suits fast, frequent cycles; multi-fall suits heavy loads and precise placing.

Highlights

  • Single or dual speed lifting; the slow step gives precise approach.
  • 24 V pendant control for operator safety.
  • Copper-wound motor and heat-treated gears; ISO M4 duty class.
  • Chain supplied to the required lifting height.
  • 2-year warranty; spare parts and service from Beta Crane.

Dimensions: 2-motion (hook suspended), mm

1 Ton Electric Chain Hoist hook suspended dimension drawing

ModelHABDEIJKLMN
BVZ-0101600520260300176ø40ø31ø40ø312424
BVZ-0102670460230280205ø40ø31ø40ø312424

H: shortest distance between top and bottom hook (headroom); A: overall length; B: hook axis to motor end; D: overall width; E: hook axis to control side; I, J, K, L: top and bottom hook opening sizes; M, N: top and bottom hook throat width.

Dimensions: 4-motion (electric trolley), mm

1 Ton Electric Chain Hoist electric trolley dimension drawing

ModelHABDEIJPKLNRT
BVZ-0101650520260300176ø31111206ø403124142231
BVZ-0102640460230280205ø31111206ø403124142231

H: shortest distance from the beam underside to the hook (headroom); A: overall length; B: hook axis to motor end; D: overall width; E: hook axis to control side; I, K, L, N: hook sizes; J, P: trolley body sizes; R, T: trolley travel motor and body width.

Request a quote for price, stock and delivery time.

Applications

Where is this capacity used?

  • Loading workpieces onto CNC machines
  • Removing and refitting parts in mould and machine maintenance
  • Freight lifts and moving loads between floors
  • Truck and platform loading

About this model

Is 1 t enough, or should I choose the next model up?

Include the weight of the hook, slings and attachments with the heaviest load. If the total is very close to this capacity, or the hoist will run continuously all day, we recommend the next capacity up.

What lifting height does it work at?

Standard lifting height: Hook suspended 3 m, trolley 6 m standard; chain to required length. If more height is needed, the chain or rope length is extended to suit the project.

Can it be used fixed, on a monorail or with a trolley?

It can be hung from its hook for fixed use or run on a monorail line with a travel trolley. Lifting speed: 1/1: 6.8 / 2.3 m/min; 2/1: 3.6 / 1.2 m/min.
